Centrifugal Pump M4

Centrifugal Pump M4
Centrifugal Pump M4

For a larger view click on the thumbnail



Technical data M4 (2.54 MB)

Normal suction, magnetically driven, leak-free centrifugal chemical pump, all wetted pump parts made of non-metallic materials in modular concept, according to CE regulations.

MARCH magnetically driven centrifugal chemical pumps operate entirely without mechanical shaft sealing. The power is transmitted to the hydraulic part by a force-locking connection using powerful permanent magnets, without physical contact. MARCH magnetically driven centrifugal chemical pumps meet maximum requirements in terms of quality, economy and reliability when pumping aggressive, toxic and environmentally hazardous liquids.

Features

  • Leak-free
  • Magnetic driven
  • Closed coupled
  • Normal suction



TECHNICAL DATA FOR THE STANDARD VERSION

Performance data

Flow rate:max. 51 l/min
Discharge head:max. 4,8 mWs

Temperatures

PP:max. 70°C
PPS:max. 90°C
PVDF:max. 90°C

Available materials

Housing:PP, PPS (Ryton), PVDF
Impeller:PP, PPS (Ryton), PVDF
Pump shaft:Ceramic
Pressure plate:Ceramic
O-Ring:EPDM, Viton, Buna, Teflon

System pressure

PP:max. 2,5 bar
PPS:max. 3,5 bar
PVDF:max. 3,5 bar

Connection on suction side

Thread 1“ NPT (f)
Thread G 1“ IG
Union bushing G 1 1/2" AG
Flange DN 25

Connection on discharge side

Thread 1/2“ NPT (m)
Union bushing G 1" AG
Flange DN 15

Motor

IEC AC or three-phase motor
1x230 V or 3x230/400 V, 50 Hz
90 Watt, 2900 1/min
